The UM760 module is an industrial-grade, multi-constellation, single-frequency navigation and positioning module developed by Unicore Communications. Based on the UC7510I, a high-performance GNSS SoC with fully independent intellectual property rights, the module features high integration, low power consumption, and anti-jamming capabilities. It supports simultaneous reception of GPS, BDS, GLONASS, Galileo, QZSS, and SBAS signals in the L1 band. The UM760 is widely used in applications such as vehicle navigation, fleet management, and vehicle monitoring.
Ordering Information
Supply at multiples of 500 pieces
Supports BDS B1I, B1C; GPS L1 C/A; GLONASS G1; Galileo E1B/C; QZSS and SBAS
Supports A-GNSS to reduce the TTFF
Built-in jamming detection and filtering technology
Compatible with UM220-IV series modules
Production process conforms to IATF16949
| Channel | 64 channels, based on UFirebird IV | |
| Frequency | GPS L1C/A | |
| BDS B1I, B1C | ||
| GLONASS G1 | ||
| Galileo E1B/C | ||
| QZSS L1C/A, L1C/B*, L1S | ||
| SBAS L1C/A* | ||
| Modes | Single-System Standalone Positioning | |
| Multi-System Joint Positioning | ||
| Time to First Fix (TTFF) | Cold Start < 26 s | |
| Hot Start < 1 s | ||
| Reacquisition < 1 s | ||
| A-GNSS: < 3 s | ||
| Positioning Accuracy (CEP) | Horizontal: 1.5 m (with SBAS) | |
| Horizontal: 2.0 m (without SBAS) | ||
| Data Update Rate | 1 Hz / 5 Hz / 10 Hz | |
| Velocity Accuracy (RMS)1 | 0.05 m/s (open sky) | |
| 1PPS | 20ns | |
| Sensitivity | GNSS | |
| Tracking -165 dBm | ||
| Cold Start -148 dBm | ||
| Hot Start -156 dBm | ||
| Reacquisition -160 dBm | ||
| Data Format | NMEA 0183, Unicore | |
Dimensions | 12.2 x 16.0 x 2.4 mm |
Package | 24 pin, LCC |
Temperature | Operating -40 °C ~ +85 °C |
Storage -45 °C ~ +90 °C |
 Voltage | 2.7V ~ 3.6 V DC |
| LNA | 2.7V ~ 3.3 V, <100 mA |
Functional Ports
| 1 × UART (LVTTL) | |
| 1 × 12C* | |
| 1 × 1PPS (LVTTL) |
| Passive Antenna, Active Antenna |
| AGNSS |
Note: * Supported by specific firmware.
1 95% at 30 m/s for dynamic operation,open sky
